Drugs Vacuum Drying Oven / Leybold Vacuum Pump High Temperature Chamber
Application
Drugs vacuum drying oven/Leybold vacuum pump high temperature chamber is special designed for dry heat sensitive, easy to decompose and oxidative substances. Some compound materials can be quickly dried through charging inert nitrogen. It is suitable for electronic, batteries, metal, plastic, communication, chemical coatings,motorcycle accessories, epoxy resin, cosmetics raw materials deaeration, magnetic material, sport equipment, scientific research units, universities and colleges, industrial and mining enterprises, laboratory, aerospace and other filed
specification
1.We are manufacturer,selling our produces.
2.Give you reasonable price.
3.Guaranteed goods high precision and stability
4. Provide our customers 1 year after sales service.
Features
1) Microcomputer electronic digital control, precision & reliability.
2) High temperature endurance & non-aging.
3) SUS#304 stainless steel inner chamber and excellent argon arc welding.
4) Forced circulation air, the temperature rise fast, even distribution.
5) PID control, double overheating protection, safety and reliability.
6) Two groups of moving plates can be adjusted height.
Technical parameter
| Specifications of drying oven |
| Model | KOV-50 | KOV-100 | KOV-200 | KOV-290 | KOV-500 |
| Interior size (W*H*D)mm | 400*350*350 | 450*500*450 | 600*600*600 | 600*950*500 | 800*1050*600 |
| Exterior size (W*H*D)mm | 1010*650*760 | 1110*800*1100 | 1260*900*1100 | 870*1590*640 | 1160*1760*880 |
| Capacity(KVA) | 3.5 | 3.5 | 4.5 | 4.5 | 6 |
| Power | AC220V±10% 1Φ 50Hz/60Hz | AC 380V±10% 3Φ4wire 50Hz/60Hz |
| Temp. range | 50 ºC~ 200 ºC( 300 ºC) |
| Temp. constancy | ±1.0 ºC |
| Temp. uniformity | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) |
| Heat up time | 50 ºC to 200 ºC within 50 min |
| Interior material | Stainless steel plate |
| Exterior material | Painted Stainless steel plate |
| Insulation material | Glass wool |
| Safety devices | No fuse breaker, over temp protection, ceramic fuse |
| Accessories | Recorder, insolating layer |
| Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available |
| specifications |
| Model | KOV-600 | KOV-720 | KOV-1000 | KOV-1800 |
| Interior size (W*H*D)mm | 1000*1000*600 | 900*1000*800 | 1000*1000*1000 | 1600*1400*600 |
| Exterior size (W*H*D)mm | 1360*1720*880 | 1300*1750*1000 | 1300*1750*1000 | 1600*1940*1200 |
| Capacity(KVA) | 6.5 | 7.5 | 8.5 | 9.5 |
| Power | AC 380V±10% 3Φ4wire 50Hz/60Hz |
| Temp. range | 50 ºC~ 200 ºC( 300 ºC) |
| Temp. constancy | ±1.0 ºC |
| Temp. uniformity | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) |
| Heat up time | 50 ºC to 200 ºC within 50 min |
| Interior material | Stainless steel plate |
| Exterior material | Painted Stainless steel plate |
| Insulation material | Glass wool |
| Safety devices | No fuse breaker, over temp protection, ceramic fuse |
| Accessories | Recorder, insolating layer |
| Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations |
Our Services
1,Pre-sales service
Before the purchase, our company will provide customers with detailed product-related information, and welcome you to visit the company and check the goods.
2,After-sales service
After the completion of the transaction, our company will be arranged different after-sales service according to the ease of the goods , and even arrange work engineers on-site service.
3,Warranty period
Our product warranty is 12 months and we are committed to responding within 48 hours of the problem, providing a solution.
