Programmable Walk-In Chamber , Environmental Test Chambers For Solar Panel Test

Name: Programmable WalkIn Chamber Environmental Test Chambers For Solar Panel Test
Brand: KOMEG
Price: 1 USD

Brand Name : KOMEG

Model Number : KMHW-4

Certification : CE/ROHS/FCC/

Place of Origin : China,Dongguan

MOQ : 1set

Price : negotiation

Payment Terms : T/T /C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow

Supply Ability : 50 sets per month

Delivery Time : 30 working days after received your payment

Packaging Details : Packed in carton firstly,and then reinforced with wooden case for outer packing

Product Name : Programmable Walk-in Test Chambers

Temp. Constancy : +/-0.5oc

Humidity Constancy : +/-2.5%R.H

Delivery : 35 working days

Application : reliability testing, research & development testing, failure analysis

System : Balanced humidiy control system

Ambient temperature : +5℃~+35℃

Contact Now

Walk In Chambers Walk in climatic/temperature test chambers

1.Advantages:

Structure:

Our housing are high-quality carbon steel with static color spray outside and galvanized steel sheet inside. Sheet metal processing machines are from Germany. Trumph is famous for its precise bending technology, so our products outlook looks quality, precise and neat.

Refrigerating System:

We use tube bending machine for copper tube bending, this way can decrease the welding points. This is easy to keep the copper tube clean to ensure longer service life of the compressor. Also less welding points can reduce the resistance when the liquid flowing inside, to keep compressor working in higher efficiency, and better energy-saving.

Water and electricity system separating design:

For improving the comparable fragile part, heating part of constant high damp heat test, we apply water and electricity system separating design, to keep the water and electricity system separated with external humidifying system, and use top brand(e.g.: DANFOSS, Schneider, Danfoss, Emerson, Saginomiya, etc. ) for all electronic components to make sure the chambers’ quality and service time.

2.Corresponding standard:

CNS:3627,3385,4159,7669,8886;

JIS:D0201,H8502,H8610,K5400,Z2371;

ISO: 3768,3769,3770;

ASTM: 8117,B268.

3. Main Technical Parameters

Model		KMHW-4(walk-in room)
Volume(m³)		9CBM
Interior Dimensions		W2100 x H2100 x D2050mm
Exterior Dimensions		W3250 x H2350 x D2250mm
Safety Devices(standard)		No fuse breaker, over pressure, over heat and over current protection for compressor, over temperature protection, over load protection for blower, dry heat protection
Standard accessories		Sight window1, cable port ( portΦ50mm ) 1, chamber lamp*1, status indicator
Control System		Balanced Temperature & Humidity Control System
Refrigeration system		Water Cooled
		Semi-hermetic compressor, single stage or cascade refrigeration system,
		CFC free refrigerant ( HFC-507 and HFC-23 )
Controller	Panel	7-inch LCD Touch panel, Chinese or English display selectable
	Operation model	Program or fix point running
	Memory capacity	120 programs,1200steps, all repeat 999 cycles,part repeat 99 cycles
	Accuracy	Temp.:0.1% of F.S ± 1 digit Humidity:0.1% of F.S ± 1 digit
	Input	Temp.: pt-100, Humidity: pt-100 or ～5V DCV
	Comm.port	RS-232 or RS-485 ( Softawre is option)
Temp. range		Maximum: 80 ºC,120 ºC; Minimum: -60 ºC, -50 ºC, -40 ºC, -30 ºC, -20 ºC, -10 ºC, 0 ºC
Humidity Range		10%, 20%, 30% ~ 95%
Temp. constancy		±0.5 ºC
Humidity constancy		±2.5%R.H
Temp. uniformity		±2.0 ºC
Humidity uniformity		±5.0%R.H
Ambient Temp.		+5 ºC～+35 ºC
Wiring method		AC 380 ± 10% 50Hz ,3 phase 4 wires + Ground Wires
Heat up time		+20 ºC～+80 ºC, Within 60 min
Pull down time		+20 ºC ~ -55 º, -40 ºC, -20 ºC, -10 ºC, Within 120 or 90 or 60 min
Interior material		Stainless Steel Plate(SUS 304)
Exterior material		Baked Painting Steel Or Stainless steel ( SUS304)
Insulation material		Rigid polyurethane foam
Door size (mm)		Single wing: W800 x H1800; Double wing: W1600 x H1800;
Note:1. We reserve the right to change specifications without prior notice 2.Customized sizes and configurations available

4. Features:

a. Touch panel for the convenient input of fixed values and programming with graphic depiction of nominal and real values, operating time, remaining cycles etc., including help functions
b. Programme memory for up to 100 programmes with a total of 1000 sections
c. Software support for potential-free inputs and outputs
d. Password protection, two-stage, to avoid unintentional alteration
e. Integrated limit value monitoring system for temperature and humidity
f. Inspection system provides information on malfunctions and collects operating time dat

5. The brand of the accessories:

6. Walk-in Room Internal Show
